HORIZON10 Toyota 4Runner (2010-2024) 10" Plug-and-Play Radio Kit

Product Highlights

Features

• Floating Mount: This design enhances visibility and ergonomics while adding a sleek and modern aesthetic to the vehicle's interior. The adjustable angle and height offer customizable viewing and easy access to controls.


• Wireless & *Wired Smartphone Integration: Access your phone's smart features by connecting through wired or wireless Apple CarPlay, Android Auto, and hands-free Bluetooth.

  • *When connecting Apple Car Play or Android Auto via USB, only USB-C connection is compatible.

• Plug-and-Play Capability: Users can easily connect the Stinger HORIZON10 Radio Kit to their vehicle's existing wiring harness without needing additional modifications or complex wiring procedures. This ensures a hassle-free installation experience, saving time and effort.


• High-Resolution Touchscreen: 10.1" 1280x800 HD screen with anti-glare, anti-reflection, anti-fingerprint film protection.

• Micro-SD Card Slot for iGO Navigation: Optional iGO Navigation integration offers reliable, offline maps. (SD Card Sold Separately)


• IP65 Weather Resistant Display: Optically bonded for dust and moisture protection*.

  • *Radio Chassis is not IP rated.

• On-Screen Accessory Control: 4 outputs allow you to control up to 4 accessories without additional switches.


• Advanced Audio Features: Enhance the overall listening experience with a 15-band equalizer, capable of saving up to six custom presets, and enjoy superior Hi-Fi audio playback. This SiriusXM Ready radio offers a vast array of music, sports, and entertainment options (SiriusXM Connect Vehicle Tuner sold separately).

• Multiple Input Options: 3 USB Inputs (1-USB-C and 2 USB-A ports), HDMI input, and AV In.

• HD Radio: Enjoy more local stations with clear digital sound, no static, and no subscription fees. Get access to additional content without the hassle of monthly payments.

• Accessory Control: Easily control up to four accessories on-screen with customizable icons (relays needed, SwitchHub recommended).

• AudioControl Compatibility: On-screen control of AudioControls's DM series processors and amplifiers for instant tweaks without the need to connect to a laptop or tablet.

• ENLIGHT10 Lighting Integration: Illuminate your ride and benefit from superior visibility with dynamic LED lighting that can be controlled on-screen.

Description

Transform your Toyota 4Runner driving experience with the Stinger HORIZON10 10" Radio Plug-and-Play Kit. This premium kit features a 10.1" HD touchscreen engineered to resist glare, reflection, and fingerprints, ensuring a clear and vibrant view in any lighting condition. Easily connect with hands-free Bluetooth and enjoy the convenience of wireless Apple CarPlay and Android Auto. Whether navigating local streets or tackling rugged trails, the IP65 weather-resistant display is built for durability and performance. Immerse yourself in high-fidelity audio with rich, detailed sound, and explore a wide range of entertainment options with SiriusXM-Ready capabilities (SiriusXM Connect Vehicle Tuner and subscription required). Navigate with precision using the optional iGO Navigation via a Micro-SD card slot (SD card sold separately) and manage up to four accessories directly from the user-friendly display. The Stinger HORIZON10 combines state-of-the-art technology, robust durability, and exceptional sound quality, delivering an unparalleled and connected driving experience.

What's in the Box

• 10-inch touchscreen display and infotainment system
• RadioPro Interface for Toyota 4Runner (2010-2024)
• Toyota 4Runner radio dash kit (SR-RUN10HX)
• Antenna adapters for satellite and AM/FM radio
• SiriusXM Adaptor (retain factory-installed SiriusXM antenna)
• Tuner sold separately & not on Stinger: SXV300V1
• Hardware kits
• Stinger USB-A (2) & USB-C extension

Guides

User Guide

Specifications

GENERAL

• Model Number: RB10RUN10X
• Operating Voltage: 10.5VDC to 16VDC
• Grounding system; Negative Ground
• Max current consumption: 15A fused

DIMENSIONS

• Radio Module: 177.7 mm x 112.96 mm x 50 mm (WxHxD)

• Display: 247.2 mm x 180.56 mm x 36.19 mm (WxHxD)

DISPLAY

• 10.1- inch Diagonal

• 16:10 aspect ratio

• 1280 × 800

• Pixels: 1,024,000

• Active area 216.96 (W) x 135.6 (H) mm

• Operating Temperature (C) -20° to 70°

AUDIO

• Load impedance: 4 Ω nominal / 2 Ω allowable

• Continuous power output: 18W x 4ch/4 Ω 20Hz to 20KHz, 1% THD at
  14.4V

• Speaker level adjustment: 0-40 steps

• Audio Preamp Output level: 4.5Vrms typical

• Audio Preamp 8 Channels: Front 1 Left, Frontl Right, Front 2 Left, Front 2 Right,
• Rear Left, Rear Right, Subwoofer Left, Subwoofer Right.

• Equalizer: (15-band) 25Hz/40Hz/63Hz/100Hz/160Hz/250Hz/400Hz/630Hz/1KHz/1.6KHz/2.5KHz/4KHz/6.3KHz/10KHz/16KHz
• Gain: +/-6dB (0.5dB/step)

• Crossover level: 10 steps

• Front 1 and Rear output: HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160Hz/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass

• Slope: 6dB, 12dB, 18dB

• Level: 0-15,1db/step

• Front 2 output: HPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160Hz/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass
  LPF: 25Hz|40Hz/63Hz|80Hz/100Hz/160Hz/250Hz/500Hz/1kHz/3.5kHz/5kHz/bypass

• Slope: 6dB, 12dB, 18dB level: 0-15,1db/step

• Subwoofer Pre-lineout: 4.5Vrms typical, 7vrms maximum without distortion

• LPF: 25Hz/40Hz/63Hz/80Hz/100Hz/160H
  z/250Hz

• Slope: 6dB, 12dB, 18dB

• Gain: 0db to 15dB (1dB/step)

• Subwoofer level: 0-15, 1db/Step Phase: 0 or 180

• Time Alignment for 8 channels: 0 to 133 steps for inches and 0-99 steps for
  9.9ms

• User Preset EQ: Rock, Hip-Hop, Electronics, Jazz, Pop, Flat.

• Source Gain: default 0db, -10 to 10 adjustable, 0.35db/Step.

• Volume Settings: Main Volume, Phone Volume, Navigation Volume, Voice Volume, Ringtone Volume adjustable separately.

• Supports Internal & External Smart DSP
• AKM AK7739 Audio Processor
• DAC- Advanced 32bit

USB

• USB 2.0 (two)

• Max current supply 1.5A

• Max storage size: 128GB

• USB Class: A

• Supports: Video/Audio/Image Media

• Playback, Charging, and Firmware Update

• USB 3.0 (one)

• Max current supply 3А

• Max storage size: 128GB

• USB Class: C

• MSC (Mass Storage Class), MTP (Media Transfer Protocol)

• File system: FAT32, NTFS
• *Supports: Apple CarPlay, Android Auto, Video/Audio/Image Media Playback, Charging, and Firmware Update
  • *When connecting Apple Car Play or Android Auto via USB, only USB-C connection is compatible.

BLUETOOTH

• V5.1 dual

• 4dBm Class2

• 2.4GHz to 2.48GHz

WIFI

• Support lEEE 802.11a/b/g/n/ac

• Support 802.11ac 1xl, Wave-2 compliant with MU-MIMO STA mode

• Complete 802.11n MIMO solution for 2.4GHz and 5Ghz band

HD RADIO™ FM TUNER

• 87.9MHz to 107.9MHz

• Usable sensitive 3dBuv (mono S/N: 30dB)

• SNR: 65dB

AM TUNER

• 530KHz to 1710KHz

• Usable sensitive 25dBuv (mono S/N: 20dB)

• SNR: 58dB

4 CAMERA VIDEO INPUTS

• NTSC, PAL, AHD 25 & 30 mhz

• Mirror Camera Image

ACCESSORY CONTROL

• 4x Accessory Control w. custom icon, name, & switch behavior

HDMI INPUT

• Supported HDMI Resolutions: 640*480p, 720*480p, 1280*720р, 1920*1080i, 1920*1080р

TOSLINK

• Output: 48khz Variable

AUDIO

• MPEG-1 Audio Layer-3 (mp3)
• FLAC (flac)
• MPEG-2 Advanced Audio (.aac)
• MPEG-4 Audio (m4a)
• Windows Audio (wav)
• OGG Audio (ogg)
• MP1
• MP2
• AAC
• AMR-NB
• AMR-WB
• APE
• PCM / ADPCM
• VORBIS
• OPUS
• WMA
• AC3/DDP
• DTS

VIDEO

• MPEG-4 Video, H.264 (.mp4)
• Microsoft AVI (.avi)
• MPG Video (.mpg)
• MPEG Video 1/2 (.mpeg)
• VOB DVD (.vob)
• Flash Video (.flv)
• MPEG-1
• MPEG-2
• H.263
• H.264
• H.265 (HEVC)
• WMV 7/8
• VC-1
• VP8
• M-JPEG


• JPEG (.jpg)
• CompuServe GIF (.gif)
• PNG (.png)
• JPEG (.jpeg)
• Bitmap (.bmp)

BACKGROUND IMAGE (USER)

• File Format: JPG / PNG
• Resolution: 1280 x 800

New Firmware

Stay up-to-date with the latest firmware for your HORIZON10! Get the newest features, enhancements, and performance improvements by visiting the product information page.

Click here to be redirected!

Warranty Information

We have a 30-day easy return policy for all purchases.

We provide a shipping label for defective products upon your return request at no cost. Non-defective products will not receive a shipping label and the consumer will be responsible for all shipping costs.

Stinger products are warrantied against defects in materials One (1) Year from purchase date. Stinger will, at its discretion, replace any products that exhibit defects in materials and/or workmanship during the warranty period. Assessments of defective parts are performed before replacements are shipped or refunds are released.

Please hold on to your order confirmation! All warranty service requires original sales receipt documentation with Order Number. The warranty only applies to the original purchaser.

Note: Products purchased from unauthorized dealers are not covered under warranty.

Warranty Limitations
Units found to have physical or liquid damage caused by use abuse or improper installation may be void of warranty.
